ASSOCIATED ROCKS OF COAL MINING AS A RAW MATERIAL FOR THE PRODUCTION OF TECHNICAL MATERIALS
DOI:
https://doi.org/10.15421/jchemtech.v34i2.347538Keywords:
coal mining rock, petrographic analysis, hydraulic activity, modulus classification, building materialsAbstract
The relevance of the work is related to solving environmental problems while reducing the use of natural resources and finding ways to create binders using industrial waste as raw materials. The research objective of the work is to investigate the petrographic and hydraulic characteristics of waste rock from the Khmelnitska and Sverdlov mines in the Luhansk region and to explore the potential for their use in the production of construction materials. The elemental composition of waste heap rocks was determined using INCA electron probe microanalysis. Petrographic studing of the samples was carried out using a MIN-8 and Nu-2E microscope in transmitted light in transparent sections. The hydraulic activity of the waste rocks was determined by the amount of absorbed lime CaO. In order to study the behavior of minerals and the amorphous phase of waste rocks at high temperatures, for example, under the conditions of the cement clinker production, sintering was carried out at tmax = 1580 °С for 10 h in an oxidizing medium of O2 and CO2. The studied rocks contain amorphous phases and a crystalline part, in which minerals muscovite, quartz, and clinochlore are presented. The rocks are classified as ultra-acidic. Sintered coal rocks consist of a glass phase in which are distributed crystals of minerals: ferruginous spinels, mullite, and pyroxenes (diopside and hedenbergite), which were formed by high-temperature reactions. The possibility of using coal mining rocks in cement production is confirmed by the similarity of their oxide compositions. The high Fe2O3 content promotes the formation of a melt, in which lime reacts better with other minerals. The combined presence of Al2O3 and Fe2O3 leads to the formation of Ca aluminoferrites with an increased aluminate content. The high content of the glass phase, the presence of Al2O3 and Fe2O3, and the excellent hydraulic properties of the rocks make them suitable for use in the production of lime-slag binders, aluminous cement, and as corrective or active additives to Portland cement clinker. By introducing rocks before sintering the raw material mixture, the Mal and Mc.f. modulus can be adjusted.
References
Agayeva, Z. R., Mammadova, B. G., Naseri, Sh. A., Jabbarov, E. E., Mammadova, S. G., Shabanova, Ch. M., Rafiyeva, Kh. L., Aliyev, E. M. (2021). Study of the mutual effect of phosphorus-containing fertilizers and clay minerals of aluminosilicate type on the productivity of agricultural products and the ecological condition of brownbrown soils. Azerbaijan Chemical Journal, 2, 54‒58. https://doi.org/10.32737/0005-2531-2021-2-54-58
Agayeva, Z. R., Mammadova, B. G., Kazimova, E. M., Talibli, I. A., Efendiyeva, S. G., Shabanova, Ch. M. (2020). Influence of alyumosilicate clays on ecological condition of Apsheron lands. Azerbaijan Chemical Journal, 1, 82‒86. https://doi.org/10.32737/0005-2531-2020-1-82-85
Gulieva, A.A. (2019). Study of the surface properties of minerals in the composition of tails of Dashkesan iron ores. Azerbaijan Chemical Journal, 4, 48‒53. https://doi.org/10.32737/0005-2531-2019-4-48-53
Khobotova, E., Kaliuzgna, Iu. (2023). [Waste blast-furnace slag as a resource for the production of slag-alkaline binders]. J. of Chemistry and Technologies, 31(3), 563−571. (in Ukrainian) https://doi.org/10.15421/jchemtech.v31i3.279211
Stadnychuk, M.Yu. (2021). [The use of industrial waste in the construction industry]. Іnternational Science Group. (in Ukrainian)
Malbasic, V. (2021). The strategy of management and utilization of mineral raw materials in the Republic Srpska through the globalization era. Archives for Technical Sciences, 25(1), 17–28.
Paziuk. V., Tokarchuk, O., Tokarchuk, D. (2025). Solution of the problem of solid waste disposal: world experience. Engineering energy transport AIC, 130(3), 113–123. (in Ukrainian)
Syvyj, M. J., Ivanov, Y. A., Panteleeva, N. B., Varakuta, O. M. (2023). The problem of rational use of mineral resources and mining waste in the context of sustainable development of regions. IOP Conf. Ser.: Earth Environ. Sci., 1254, 012134. https://doi.org/10.1088/1755-1315/1254/1/012134
Shalamanov, V., Pershin, V., Shabaev, S., Boiko, D. (2017). Justification of the optimal granulometric composition of crushed rocks for open-pit mine road surfacing. The 1st scientific practical conference “International innovative mining symposium”, 15, 01006.
Zhang, L. (2013). Production of bricks from waste materials. A review. Construction and Building materials, 47, 643–655. https://doi.org/10.1016/j.conbuildmat.2013.05.043
Klassen, V., Borisov, I., Manuilov, V., Khodykin, E. (2017). [Theoretical substantiation and efficiency of the use of coal waste as a raw material component in cement technology]. Construction Materials, 8, 20–21. (in Ukrainian)
Khobotova, E., Datsenko, V. (2026). Coal mining waste as a prospective mineral resource. Petroleum and Coal, 68(2), 482‒489.
Misz-Kennan, М., Fabiańska, M. (2011). Application of organic petrology and geochemistry to coal waste studies. Intern. J. Coal Geology, 88: 1–23. https://doi.org/10.1016/j.coal.2011.07.001
Gong, D., Song, Y., Wei, Y. et al. (2019). Geochemical characteristics of Carboniferous coaly source rocks and natural gases in the Southeastern Junggar Basin, NW China: Implications for new hydrocarbon explorations. Intern. J. Coal Geology, 202, 171–189. https://doi.org/10.1016/j.coal.2018.12.006
Kotlyar, V.D., Yavruian, Kh.S. (2017). Thin issues products of processing waste heaps as raw materials for ceramic wall products. MATEC Web of Conferences, 129, 05013. https://doi.org/10.1051/matecconf/201712905013
Dvorkin, L.Y., Myronenko, A.V. (2019). [Building materials and products using industrial waste]. Rivne: NUVGP. (in Ukrainian)
Giménez-García, R., de la Villa Mencía, R., Rubio, V., Frías, M. (2016). The transformation of coal-mining waste minerals in the pozzolanic reactions of cements. Minerals, 6, 64–74. https://doi.org/10.3390/min6030064
Khobotova, E., Ihnatenko, M., Kaliuzhna, Iu., Hraivoronska, I. (2021). Evaluation of Radiation Security of Coal-Mining and Thermal Power Waste Products. Petroleum and Coal, 63(2), 517‒524.
Lyalyuk, V.P., Shmeltser, E.O., Kassim, D.A., Lyakhova, I.A. (2020). Influence of the properties raw coal materials and coking technology on the granulometric composition of coke. Message 2. Granulometric composition of the coke as a function of the coal batch properties. Petroleum and Coal, 62(2), 309‒315.
Khobotova, E., Ukhanyova, M. (2010). [The method of determination of useful properties of industrial waste for the purpose of their utilization as technical materials]. Author’s license No. 34221 UA. (in Ukrainian)
DSTU EN 14899:2022 [Waste characterization. Waste sampling. Principles for preparing and applying a sampling plan]. (in Ukrainian)
DSTU EN 934-6:2022 [Admixtures for concrete and mortar - Part 6: Sampling, evaluation and verification of stability of performance]. (in Ukrainian)
DSTU B А.1.1-44-94 [Mineral raw materials for the production of binders. Terms and definitions]. (in Ukrainian)
Dvorkin, L.Y., Lapovska, S.D. (2024). [Construction materials science]. Kyiv: Condor. (in Ukrainian)
Kholin, I. I. (1963). [Handbook of cement production]. Moscow: State Building Publishing House. (in Russian)
Kutsevol, M.L., Nesterovsky, V.A. (2021). [Fundamentals of general mineralogy]. Dnipro: NTU "DP". (in Ukrainian)
Gill, R., Fitton, G. (2022). Igneous Rocks and Processes (2nd ed.). Wiley.
Plemyannikov, M. M., Zhdanyuk, N. V. (2022). [Рhysical chemistry of refractory non-metallic and silicate materials]. Kyiv: "Education of Ukraine". (in Ukrainian)
Pavlov, G.G. (2014). [Petrography]. Kyiv: VPC “Kyiv University”. (in Ukrainian)
Gurskiy, D. S., Esipchuk, K. Yu., Kalinin, V. I. (2006). [Metallic and non-metallic minerals of Ukraine: In 2 vols. T. 2. Non-metallic minerals]. Kyiv: Center of Europe. (in Ukrainian)
Jastzrebska, I., Szczerba, Ja. (2024). Design, nanufacturing and properties of refractory materials. Materials, 17, 1−4. https://doi.org/10.3390/ma17071673
Chobotko, I.I. (2022). Creation of a classification of methods for using coal mining waste]. Physical and technical problems of mining production., 24. 128–141. (in Ukrainian)
Perkins, D. (2022). Petrology: An introduction to igneous and metamorphic rocks and processes. Grand Forks: University of North Dakota.
Sokoltsov, V.Yu., Tokarchuk, V.V., Svidersky, V.A. (2015). [Use of heat-treated coal mining waste rocks in cement production]. Technology audit and production reserves, 6/4(26), 55–58. (in Ukrainian)
Sivak, R. (2021). [Features of processing of technogenic industrial waste in the construction industry]. Vinnytsia: VNTU. (in Ukrainian)
